POWER SUPPLY

• ◆ AC100V-250V,50/60Hz

• ◆ Power 180W

OPTICS

• ◆ Laser: RGB500MW/1W *6

• ◆ Colour spectrum: RGB

• ◆ Laser sources: Semiconductor pumped all solid state laser

• ◆ Laser modulation: TTL

FEATURES

• ◆ X-axis scan: 0-270 degrees

• ◆ Y-axis scan: 0-180 degrees

• ◆ X/Y axis fine adjustment: 0-270 degrees

CONTROL

• ◆ Channels: 11/26/38 CH

• ◆ DMX input: XLR 3-pin male

• ◆ DMX output: XLR 3-pin female

• ◆ Standard control signal: DMX512

• ◆ Control mode: DMX512, self-propelled mode, sound control mode, master-slave

• ◆ Surface: aluminium

• ◆ Color: black

• ◆ IP Rating: IP20

SIZE

• ◆ Product Size: 910*340*300mm

• ◆ Package Size: 1000*480*310mm (2pcs)

WEIGHT

• ◆ Net Weight:10kg

• ◆ Gross Weight: 11kg/1pcs ; 30kg/2pcs
