POWER SUPPLY

• ◆ AC100V-240V/50-60Hz

• ◆ Power 300W

OPTICS

• ◆ LED: 200W white LumiEngin

• ◆ Color Temperature(CCT): 7500K

• ◆ Average lifetime: 50,000 hour

• ◆ Zoom angle: 7-21 degree

• ◆ Scanning speed: Pan: 540 degree + fine Tilt: 270 degree + fine

• ◆ Color wheel: 9 colors + open, with half color effect

• ◆ Static Gobo Wheel: 9 gobos + open, with rotation and running water effect

• ◆ Rotation gobo wheel: 7 gobos+open

EFFECTS

• ◆ Prisms:  4 facet prism with bi-direction rotating

• ◆ Frost: Soft light effect, easy to achieve the effect of soft and fantasy pattern

• ◆ Strobe: 1-25 Hz with pulse effect

• ◆ Dimmer: 0-100% smooth linear dimmer

CONTROL

• ◆ Channel: 18CHs

• ◆ Standard control signal: DMX512

• ◆ Control mode: international standard DMX512, automatic master/ slave mode

• ◆ Screen: LCD screen with Chinese and English, can adjust 180 degree to fit different
  installation position

HOUSING

• ◆ Surface: High temperature resistant plastic

• ◆ Color: black

• ◆ IP Rating: IP20

• ◆ Size: 343*239*537mm (LWH)

• ◆ Size: 460*460*580mm (Carton)

• ◆ Net Weight: 14.5kg

• ◆ Gross Weight:23kg
